|  | | Technical Information |  |  | Processor: Intel Pentium® MMX | | Clock Speed: 233 MHz; PII 266 MHz | | Chipset: T-Chipset | | RAM: 32 MB (optional up to 128MB) | | | | |
| |
| | | | Passive PCI/ISA-Bus | 6 free long ISA Slots | | 1 half-size ISA/PCI shared slot | | 1 long PCI slot (only PII version) | | 1 CPU slot | | 1 empty panel for COM2 | | AT format | | | | Temperature | non-operating: -25 ºC - +60 ºC | | operating: +5 ºC - +50 ºC | | | | Operating Height | non-operating: 30,000 ft. | | operating: 10,000 ft. | | | | | | | Power Supply | AC Input Ratings 110/220 VAC | | Total Power Output 200 VA max. | | Max. Output Current + 5 V/min. 20 A | | + 12 V/min. 8 A | | - 12 V/min. 0,5 A | | - 5 V/min. 0,3 A | | | | Humidity (non-condensing) | non-operating: 5 - 95% | | operating: 20 -80% | | | | Shock (according to IEC 68-2-27) | non-operating: 30 g, 11 ms | | operating: 15 g, 11 ms | | | | |
| | Interfaces | 1 x serial RS232 | | 1 x serial RS232/RS422/RS485, switchable | | 1 x parallel ECP, EPP capable | | | | Keyboard | Front panel 55-key membrane keyboard | | Function keys F1 - F10 below and 45 -key field to the right of the display | | Add. keyboard connector on front panel | | Folding front panel for maintenance access | | | | Electromagnetic Compatibility | CE conformity* | | | | | Mass Storage | Hard Disk (EIDE) > 1 GB | | Floppy Disk Drive 3.5", 1.44 MB, on front panel | | 5.25" drive port e.g. for an optional CD-ROM, on front panel | | | | LED Status Indicators | Operating indicator | | hard disk access | | temperature | | keylock | | | | Safety | DIN VDE 0805, EN60950, IEC950 (TÜV) | | | | |
| | Mechanical Data | Front Panel: 19" x 6 U | | Dimensions: approx. 450(W)x263(H)x300(D) mm | | Weight: approx. 18.5 kg (standard conf.) | | | | Vibration (according to IEC 68-2-6) | non-operating: 10-58 Hz/+0.075 mm, 58-500 Hz/1.0 g | | operating: 10-58 Hz/+0.035 mm, 58-500 Hz/0.5 g | | | | Protection Class (IEC 529, EN 60529) | front panel IP65 | | rear panel IP20 | | | | | External Monitor | max. 1024 x 768 pixels, 256 colors, 75 Hz | | 640 x 480 pixels, 16.7 million colors, 60 Hz, 64k colors, 75 Hz | | VGA, VESA compatible | | | | Internal Display | TFT active color display | | VGA, VESA compatible | | 12.1" (30.7 cm) 1024 x 768 pixel with 256 colors (only PII) or | | 12.1"/ 10.4" 640 x 480 pixel with 16.7 Mio. colors | | | | |
| *) The CE mark approves the conformity with all applicable standards of the European Community.
|
